Build a REST API using Node and Express.js

Hello Sailors, if you are a programmer you would have heard about APIs or have developed APIs in JAVA, Python or any language. Today, we are going to build an API which sends random nutrition tips as response, with Nodejs and Express.js. Sounds interesting!
What is an API? API stands for Application Program Interface. Ho ho ho! this just made my life, what an explanation! Well, an API is a set of functions and procedures that allow you to create applications which access the data of an application or service.
Why do we need an API? When we want to build an android application, a web application and a desktop application because there are different type of users, so instead of building separate logic for all of these applications, we will build an API and all these applications will consume this API and serves the purpose. Here's another example : You have built a printer which prints great on paper but still no one buys it because you do not provide them any tool to communicate…

Build a facebook chatbot with API.AI (zero coding)

Hello Sailors, chatbot has been the buzz-word these days, many businesses are looking to implement chatbots to their sites or facebook pages to convert traffic into customers. Today in this tutorial, we are going to create a simple conversational facebook chatbot which can send you jokes, images and also it can do a small talk.

Messenger bots simply blend artificial intelligence with human interaction. User asks a question and chatbot gives relevant answer to serve the purpose.
What do we need to build our facebook chatbot?API.AI account - A natural language understanding platform to design and integrate intelligent sophisticated conversational user interfaces.Facebook for developers account - To create a facebook app.Facebook page - Chatbot feature is only available to pages, not personal accounts. What we are going to do We are going to subscribe our API.AI agent to read all messages we receive on our Facebook page and in turn our agent processes the message and responds the way we…

Automate irrigation system over internet

Hello Sailors! We are back with one more awesome IOT project where we are going to automate irrigation system. The system can be used in homes to water the plants any time and can also be scheduled so even if you forget to water plants (lazy like me), just schedule the device and your plants get water regularly. That's another great use of IOT, aah!
Overview We are going to control an AC water pump using NodeMCU/ESP8266 and blynk application. The Blynk app will have a switch controlling the pump to switch ON/OFF and an Eventor widget to schedule our pump switching with time. This way plants can be irrigated by manual switching or by scheduling with time.
Things we needHardwareNodeMCU/ESP82665V relayWater PumpWater pipes (0.5 inch)Water flow splitterWater containerPipe clampsJumper Wires5V and 3.3V power supplySoftwareArduino IDEBlynk app If you have already setup the Time Scheduled electric switchgo ahead to setup the water system because this is what we are going to use to schedu…

Setup Mosquitto MQTT broker in Windows

MQTT (Message Queueing Telemetry Transport) is a Client Server messaging transport protocol. It provides a lightweight method of carrying messages using a publish/subscribe model. The pub/sub model being lighweight makes it suitable for IOT messaging with low power devices, sensors, phones or microcontrollers. How MQTT works? MQTT follows publish/subscribe model which is alternative to server-client model where client communicates directly with server. The pub/sub model defines the client which send a message(publisher) to another client which received that message(subscriber). The subscriber and publisher are unaware of the presence of each other. The main part, which we call the Broker, which our both publisher and subscriber are aware of, filters all the coming messages and distributes them respectively.

Now we know what is MQTT and how it works. Let's dive in to set this up on Windows 7/8/10.
Mosquitto: This is an open source message broker used for handling lightweight data t…

Time scheduled electric switch controlled with Blynk app

Most of the times when we go out of home for some days, we think of having some device that could switch ON/OFF (let's say) Refrigerator (or any other important appliance)for some hours during the day. Today, we are going to make such time scheduled electric switch which switches ON/OFF at times which we set the in our Blynk app. Woah!

Let's begin!
Things we need:
Hardware:5V relayNodeMCUJumper wiresBreadboard3V3 and 5V power sourceElectrical WiresSoftware:Arduino IDEBLYNK app It's circuit is same as we have created for our Smart Switch. So, if you already have that circuit set up, go ahead with Blynk app set up and Start playing.
Circuit:
Connections:D5 pin of NodeMCU connects to IN1 pin of 5V relay.3V3 of NodeMCU connects to 3V3 powers source and GND to GND.Vcc of relay connects to 5V source and GND to GND.Live wire is connected directly to appliance.Neutral wire from source comes to relay NC pin and another wire goes out from COM pin which is connected to the appliance.Let…

Control switch over internet with BLYNK

Yo... yo... yo... Shippers! It's been quite a few days that we have not built anything awesome. Come let's gather up the stuff and get ready to roll. Today, we are going to control switch over internet using our very precious BLYNK app, let's call this Smart Switch. Cool!
Overview: The 5V relay connected to D5 pin of NodeMCU goes ON when D5 pin is set LOW and relay goes OFF when D5 pin is set HIGH.

We are simply going to set D5 pin HIGH to turn ON the appliance and D5 as LOW to turn OFF the appliance, considering the neutral wire is passing through the NC and COM of the relay.
Stuff required:Hardware:5V relayNodeMCUJumper wiresBreadboard3V3 and 5V power sourceElectrical WiresSoftware:Arduino IDEBLYNK appCircuit:
Connections:D5 pin of NodeMCU connects to IN1 pin of 5V relay.3V3 of NodeMCU connects to 3V3 powers source and GND to GND.Vcc of relay connects to 5V source and GND to GND.Live wire is connected directly to appliance.Neutral wire from source comes to relay NC pin and…

Home made temperature and humidity meter

Hello Shippers! Once again, it's time to create something awesome. How about a temperature and humidity sensor controlled with NodeMCU or ESP8266 which sends the temperature of your room and our very special Blynk app shows the data with values and graphs. That sounds cool!

Let's sail.
Overview: The NodeMCU collects the temperature and humidity from DHT11 sensor and sends it to Blynk app every second. Wow!
Things we need:Hardware:NodeMCUDHT11/DHT22 sensorJumper Wires4K7 resistor3V3 power sourceSoftware:Arduino IDEBlynk app Now that we have gathered all the stuff we need. Let's connect them.
Temperature and humidity sensor circuit:
Connections:D4 pin of NodeMCU connects to pin 2 of DHT11.3V3 pin of NodeMCU connects to pin 1 of DHT11 & GND of NodeMCU to pin 4 of DHT11.4K7 ohm resistor connected between pin 1 and pin 2 of DHT11 sensor.Connect power(3.3V) to NodeMCU to make it work without USB cable. Before we dive into the code, let's setup the Blynk app to receive the d…

Controlling Servo Motor with BLYNK app over WiFi

Hello Shippers, hope you are having a great time! Today, we are gonna build a simple project of controlling servo motor with BLYNK app over Wifi.
Overview: The slider on the blynk app will send a value to the NodeMCU/ESP8266 and this value will be written on PIN 8 and the servo rotates that much degrees. That's the way we are controlling servo motor. Ahaa!


Things we need:Hardware:Servo SG90NodeMCUMicroUSB cableJumper WiresSoftware:Arduino IDEBLYNK appCircuit:
Connections:D8 pin of NodeMCU connects to Command pin of Servo Motor.3V3 PIN of NodeMCU connects to Power PIN of Servo motor (usually RED one).GND PIN of NodeMCU connects to GND of servo motor (usually BLACK one). Simple connections, huh!
BLYNK app Setup on phone:Create a New Project in BLYNK app.Write Project Name and Select ESP8266 or NodeMCU from dropdown.An AUTH token will be sent to your registered email, note this down.Tap on the screen and add a SLIDER widget on the screen.Tap on the Widget, select Digital PIN 8 and Start…

Color changing LED Strip with BLYNK app

Hello Sailors! Have you ever thought to own a color changing LED strip, so you could change it's color based on your mood, yes I am taking about Mood Light. Today,  we are back with one more interesting IOT project where are going to create a mood light(LED strip) with BLYNK app. Sounds Romantic, hmm!

Let's Rock' n Roll.
Overview: BLYNK app will send message to your NodeMCU over Wifi, these signals will be translated by NodeMCU and LED strip will change color as received in the message.
Things we need:Hardware:SMD 5050 Led Strip (Color changing LED strip)Jumper WiresTIP 120/122 NPN transistor Buying this from local shops would be a better option12V & 3.3V SupplySoftware:Arduino IDEBLYNK AppCircuit: Connections:D5 pin is connected to TIP 120 NPN(U1) transistor's Base pin.D6 pin to Base pin of U2.D7 pin to Base pin of U3.U1, U2 and U3's Collector pins are connected to respective LED color pinU1, U2 and U3's Emitter pins are grounded. Grounded, That's sad!No…

Internet controlled switch using NodeMCU and MQTT

Hello Sailors! Today we are going to build an internet controlled switch. Woah! Internet controlled Switch, sounds cool! With this switch we will be able to switch ON/OFF our appliances from anywhere in the world like a BOSS.
What's NodeMCU? NodeMCU is an open-source IOT module which is based on ESP-12 module, we can create WIFI Access point with this or connect this to our wifi router and then control relays, servos etc. over internet or wifi.
What's MQTT? MQTT is a light weight messaging protocol for small sensors and mobile devices. It consists of a broker(can be on cloud or local network) which routes the messages from publisher to subscriber.

In this project, we will be sending message to NodeMCU which is connected to the internet. The NodeMCU then switches the relay ON/OFF based on the message received. Sounds genius!
How this works? We are going to create an MQTT topic and make our NodeMCU it's subscriber and MQTT dash, the publisher. MQTT  dash will publish the comma…
